XLSLPLN25XSVMP2

• Numerical Aperture (NA): 0.95
• Working Distance (WD) [mm]: 8
• Objective Field Number: 18
• Coverglass Thickness [mm]: 0 - 0.23
• Immersion Medium: Water (Scaleview-A2, Silicone Oil, Normal Oil Available)
• Correction Collar: Yes
• Objective Type: Other
• Parfocal Distance [mm]: 75
• Back Focal Plane (BFP) Position [mm]: -48.1
• Mounting Threads: M25X0.75
• Reflected Brightfield (BF): N/A
• Transmitted Brightfield (BF): Limitation
• Reflected Darkfield (DF): N/A
• Transmitted Darkfield (DF): N/A
• Reflected DIC (Visible): N/A
• Transmitted DIC (Visible): Limitation
• Polarization (PO): Limitation
• Fluorescence (B & G excitation): Limitation
• Fluorescence (UV excitation : 365nm): N/A
• Multi photon excitation (MPE): Good
• Compatible for Autofocus: N/A
• IR Through Si or Glass: N/A
• TIRF (Total Internal Reflection Fluorescence): N/A
• WLI (White Light Interferometry): N/A
• 340nm Transmittance: N/A
• 700-1000nm Transmittance: Yes
• 1000-1300nm Transmittance: Yes
• Magnification: 25
• Relief Contrast (RC): N/A
• Phase Contrast (PH): N/A
• With Coverglass: Yes
• Variable Coverglass: Yes
• Without Coverglass: Yes
