Tissue-Tek Xpress® x120

Contact Us

Overview

The Tissue-Tek Xpress® x120 enables fast and continuous tissue processing, delivering standardized, high-quality results that are compatible with IHC and molecular pathology techniques.
Features

Features:

  • Continuous magazine loading every 20 minutes
  • The x Series are pre-programmed with two rapid protocols: standard and extended
  • The x Series reagents are prepackaged in containers that are placed directly onto the instrument
  • Tissue-Tek Xpress proprietary reagents are formalin- and xylene-free

Benefits:

  • Provides a steady flow of processed tissues for embedding
  • Enables continuous, rapid processing of both biopsy and larger tissue
  • Makes exchanging reagents fast, simple, and error-free by eliminating reagent dilution, pouring, or placement mistakes
  • Allows for a greener work environment by eliminating exposure to harsh chemicals and reducing waste
Benefits
Other Contents

Workflow Benefit:

  • Work in a standardized way for high-quality processed tissue
  • The Xpress x120 allows continuous loading, streamlining your laboratory's workflow
  • Fast processing and shorter turnaround times—compatible with IHC and molecular pathology
  • Enables same-day diagnosis, helping reduce patient stay and anxiety

Need assistance?

Get in Touch

Specifications

Product name
Tissue-Tek Xpress® x120 Rapid Tissue Processor
Product code
7720
Application
Continuous rapid processing of human or animal tissue for routine clinical and research histology
Power requirement
Single phase, 200 VAC ± 10%, 50/60 Hz, 15 A
(NEMA L6-20 dedicated receptacle)
Dimensions (W× D × H)
170 × 71 × 162 cm (67 × 28 × 64 in.)
Weight
465 kg (1,023 lb)
Retorts
Load station—1 station
Retorts—4 retorts
Unload stations—2 stations
Capacity
Up to 40 cassettes, every 20 minutes
Processing programs
Standard up to 2mm; 60 minutes or
Extended up to 3mm; 120 minutes
Temperature ranges
Processing stations #1 and #2:
51° C ± 1° C (123.8 °F ± 1.8 °F)
Processing stations #3 and #4:
65° C ± 2° C (149 °F ± 3.6 °F)
Certifications
Complies with:
UL 61010-1: 2nd Ed.: 2004,
CAN/CSA-C22.2 No. 61010-1: 2nd Ed.: 2004,
CAN/CSA-C22.2 No. 61010-2-010:04,
IEC61010-2-010: 2003
CAN/CSA-C22.2 No. 61010-2-081:04,
IEC61010-2-081: 2001
CAN/CSA-C22.2 No. 61010-2-101: 04,
IEC61010-2-101: 2002
FDA Registration (Regulation No. 864.3875)
FDA Certified with ETL evaluation
Regulatory status
IVD, FDA Class I

Consumables

Product Code
Product Name
7720
Tissue-Tek Xpress® x120 Rapid Tissue Processor
7103
Tissue-Tek Xpress® 40-Cassette Basket with Handle and Lid
7104
Tissue-Tek Xpress® 40-Cassette Basket Lid
7106
Tissue-Tek Xpress® Tray Liners; 100/case
7107
Tissue-Tek Xpress® x120 Fume Filter; 2/case
7115
Tissue-Tek Xpress® Pre-Processing Solution; 4 × 3.8 L/case
7117*
Tissue-Tek Xpress® Pre-Processing Fixative; 4 × 3.8 L/case
7120*
Tissue-Tek Xpress® Molecular Fixative; 4 × 3.8 L/case
7730
Tissue-Tek Xpress® x120 Processing Reagent Set
7760
Tissue-Tek Xpress® x50 Processing Reagent Set
7011
x120, Uninterrupted Power Supply (1.5 hours)
4800
Tissue-Tek® Accu-Edge® Grossing Board
4802
Tissue-Tek® Accu-Edge® Grossing Wells
4848
Tissue-Tek® Accu-Edge® Grossing Wells, Left-handed
4803
Tissue-Tek® Accu-Edge® Grossing Fork, 1.5 mm
4804
Tissue-Tek® Accu-Edge® Grossing Fork, 2.0 mm
4807
Tissue-Tek® Accu-Edge® Grossing Fork, 2.5 mm
4814
Tissue-Tek® Accu-Edge® Cleaning Brushes
4846
Tissue-Tek® Accu-Edge® Tamper Set
4847
Tissue-Tek® Accu-Edge® Gauge Set
4220
Histo-Tek® Biopsy Bags, Small
4221
Histo-Tek® Biopsy Bags, Medium
4223
Tissue-Tek® Biopsy Bags Small; 1,000/case
4224
Tissue-Tek® Biopsy Bags Medium; 1,000/case
4785
Tissue-Tek® Accu-Edge® Trimming Blades, Short
4786
Tissue-Tek® Accu-Edge® Trimming Knife Handle, Short Straight
4789
Tissue-Tek® Accu-Edge® Trimming Blades, Long
4790
Tissue-Tek® Accu-Edge® Trimming Knife Handle, Long Straight
4791
Tissue-Tek® Accu-Edge® Dissecting Scalpel Handle
4792
Tissue-Tek® Accu-Edge® Dissecting Scalpel Blades, #61, Curved Tip; 20/case
4793
Tissue-Tek® Accu-Edge® Dissecting Scalpel Blades, #62, Pointed Tip; 20/case
6040
Tissue-Tek VIP® 6 AI Vacuum Infiltration Processor
7090
Tissue-Tek AutoTEC® a120 Automated Embedder
