DP75

DP28

DP23

SC180

Pixel size (μm)

3.45 x 3.45 µm

3.45 x 3.45 µm

2.4 × 2.4 μm

1.25 × 1.25 μm

Number of pixels (MP)

49.1

8.9

6.4

18

Image Sensor

1.1 inch 12.37 megapixel color CMOS image sensor, global shutter

1 in. color CMOS

1/1.8 inch Color CMOS

1/2.3 in. color CMOS

Frame rate (fps)

at max resolution

*1 Max. 22 fps at 4096 × 3000 (Full Resolution)
Max. 22 fps at 2048 × 1500 (2 × 2)
Max. 44 fps at 2048 × 1500 (1 × 1)
Max. 60 fps at 1920 × 1080 (1 × 1, Full HD)

Max.32 fps at 4104 × 2174 (Full Resolution)
Max.33 fps at 3840 × 2160 (4K)
Max.33 fps at 2168 × 2168 (Square)
Max.64 fps at 1920 × 1080 (Full HD) *1

Max.45 fps at 3088 × 2076 (Full Resolution)
Max.58 fps at 2072 × 2072 (Square)
Max.60 fps at 1920 × 1080 (Full HD) *1

10.5 fps at 4,912 × 3,684 pixels (4:3)
23.6 fps at 2,456 × 1,842 pixels (4:3)
45 fps at 1,224 × 920 pixels (4:3)
14 fps at 4,912 × 2,762 pixels (16:9)
25 fps at 3,840 × 2,160 pixels (4K UHD 16:9)
31 fps at 1,920 × 1,080 pixels (Full HD 16:9)
59 fps at 1,224 × 688 pixels (16:9)

Connector

USB 3.1 Gen2 (Type-A)

USB 3.1 Gen1 *2

USB 3.1 Gen1 *2

USB 3.0

Color

• Color

• Color

• Color

• Color

Observation Method

• Brightfield
• Fluorescence
• Infrared

• Brightfield
• Fluorescence

• Brightfield
• Fluorescence

• Brightfield

Remark

*1 Frame rate may decrease depending on the condition of your PC, monitor resolution, and/or software.
*5 Operatable with a USB 3.1 Gen1 (5 Gbps) connector, but framerate is decreased.
Not available in the combination of cellSens Entry or DP2-TWAIN.

Focus Peaking manual focus assist
OSIA - Olympus Smart Image Averaging (active noise reduction)
*USB 3.1 Gen1 is compatible with USB 3.0

Focus Peaking manual focus assist
OSIA - Olympus Smart Image Averaging (active noise reduction)
​*USB 3.1 Gen1 is compatible with USB 3.0

Focus Peaking manual focus assist
OSIA - Olympus Smart Image Averaging (active noise reduction)
